AQUALAB3 water activity meter

Choose Models for offer request

Intended

  • iso-9001-copy
  • shape-2601
  • shape-2680
  • iso-9001-copy
  • shape-2601
  • shape-2680
  • Quick measurement - even 1 min
  • Precise measurement
  • Expandable
  • Possibility to connect other devices
AQUALAB3 water activity measuring instrument

System with Nexus device, iPad, cleaning starter kit, dishes and templates.

The AQUALAB3 takes only 1 minute to read a single sample. It provides 10 times the accuracy of the average moisture content. Precise, reliable readings enable more accurate moisture specifications.

The units can be stacked on a small footprint to save space. An intuitive iPad is also included to manage the AQUALAB3.



Advantages:

- rapid - water reading within 1 minute
- easy to use - precise measurements with minimal training
- expandability - connect and manage multiple AQUALAB3 devices with a single iPad
- repeatability - certified repeatability standards for users and locations
- multiple readings - simultaneous moisture content readings
- optional block replacement program - include annual recalibration, extended warranty and service plan

Technical specification:

TECHNICAL DATA

WATER ACTIVITY

RANGE aw

0,030 – 1,000

RESOLUTION aw

0,0001

ACCURACY aw

±0,005 aw (dew point)

±0,015 aw (volume)

REPEATABILITY aw

0,002 aw (dew point)

0,010 aw (volume)

HUMIDITY

ACCURACY

0,1% - 0,5% RELATIVE TO THE REFERENCE MOISTURE CONTENT

REPEATABILITY

0,02%

TEMPERATURE

RESOLUTION

0,1°C

ACCURACY

±0,1°C

MEASUREMENT TIME

MIN

60 SEK (ONE-MINUTE WATER ACTIVITY)

MAX

200 S

SAMPLE CUP VOLUME

RECOMMENDED

7,5 ml – PARTIALLY FULL

FULL

15 ml

CASE DIMENSIONS

LENGTH

23,4 cm

WIDTH

23,4 cm

HEIGHT

12,1 cm

OPERATING TEMPERATURE

MIN

15°C

MAX

35°C

WORK ENVIRONMENT

0 TO 90% RELATIVE HUMIDITY (NON-CONDENSING)

POWER SUPPLY

110 – 240 VAC

CERTIFICATES

ISO 9001:2015

EM ISO/IEC 17050:2010 (CE SIGN)

WEIGHT

5 kg

COMMUNICATION

USB-A I USB-B




Model Parameter Description Scale
AQUALAB3 water activity, temperature Dew point with cooled mirror 5 kg
