BiOptima ONE Laminar Flow Cabinet of Safety Class I with electric sliding of the front window

BIOPTIMA ONE laminar flow cabinets are designed to the highest standards of safety, ergonomics, energy efficiency, reliability, and ease of use in their class.

They feature a very spacious working area within an elegant, compact enclosure.

The front window of the cabinet is made of safe anti-reflective glass. Inclined at a 7-degree angle, it can be opened up to a height of 200 mm, significantly improving ergonomics and work comfort. An additional advantage is the raised, corrosion-resistant, patented V-shaped armrest integrated with air inlet grilles, which prevents blockage of the air intake holes.

Technical Specifications of Laminar Flow Cabinets:

• Class I safety cabinets guarantee a high level of safety for the operator and the environment.
• Work parameters controlled by a microprocessor controller
• Color LCD display, installed at an angle, with a digital screen and a touch panel, displaying airflow velocity messages, alarm states, UV lamp operation, filter usage level, filter clogging message, and values in percentage.
• Possibility to operate the cabinet in "stand-by" mode
• Possibility to operate the cabinet in a 30/70 mode
• Possibility to operate the cabinet in a decontamination program mode
• Equipped with audible and visual alarm states
• Active monitoring of filter usage level
• Automatic UV lamp start
• Automatic UV lamp shutdown when the front window is opened
• Possibility of chamber disinfection using formaldehyde
• Ability to control LED lighting, power outlets, and electric valves from the controller
• The display shows:

Current values for laminar airflow velocity, exhaust airflow, and inlet airflow, information about the frequency of filter integrity tests, UV lamp lifespan, filter lifespan, total hours of operation for the laminar flow cabinet, fan(s), UV lamp, filters, information about the last service inspection

• Software available in English, Spanish, French, German
• Control panel access protected by a password
• Cabinets equipped with a manual front panel opening mechanism, allowing full access to the working space, e.g., for inserting larger objects or thorough chamber cleaning
• In front of the working surface, there is a patented, removable, V-shaped armrest to prevent blockage of airflow
• The front window of the cabinet is made of safe anti-reflective glass, inclined at a 7-degree angle, with UV radiation protection, and it is automatically sliding
• A silicone seal is mounted around the front window
• The work surface is made of 304L stainless steel, divided, and some parts can be autoclaved
• The working surface and the chamber are made of 304L stainless steel with rounded corners; the sides of the chamber are made of tempered glass
• The cabinet enclosure is made of powder-coated steel
• A drip tray is installed under the work surface, capable of collecting up to 4 liters of spilled fluids (in accordance with EN 12469)

Standard Equipment:

• HEPA 14 filter compliant with EN 1822: 99.995% MPPS and 99.999% DOP efficiency, providing air cleanliness: ISO 4 according to ISO 14644-1: 353 particles > or = 0.5µm/m3; 10000 particles > or = 0.1 µm/m3
• G3 pre-filter compliant with EN 779, installed below the work surface, preventing dust, dirt, and particles from entering the HEPA filter, significantly extending the HEPA filter's lifespan (up to 7 years), and preventing potential damage to fans due to contamination in the technical area (pipette tips, aluminum foil, etc.)
• 4F (fast, friendly & efficient) filter exchange system
• Electrically operated front window
• Built-in anemometric airflow sensor
• LED lighting, providing uniform chamber illumination, protecting against eye fatigue, installed outside the working chamber
• Two 230V, 50Hz electrical outlets
• Fan(s) with EC motors
• 304L stainless steel work surface, divided
• UV lamp with programmable operation time
• Replaceable CG screen ensuring the best laminar airflow

Optional Equipment:

• Powder-coated steel frame for the cabinet with 800mm high adjustable feet
• Powder-coated steel frame for the cabinet with 900mm high adjustable feet
• Set of casters for the frame
• Gas valve
• Vacuum valve
• Oxygen valve
• Inert gas valve
• Compressed air valve
• Water valve
• Humidity sensor
• Temperature sensor
• USB port
• Burner
• Formaldehyde vaporizer
• External fan
• Activated carbon box
• 21.5" LCD monitor, installed on the rear wall of the cabinet, with 1x HDMI, 2x USB ports
• VHP decontamination kit
• FAT and SAT documentation
• IQ and OQ documentation
