Magnetic stirrers M series
Choose Models for offer request
Intended
- Magnetic stirrer without heating
- Infinitely variable speed control
Characteristic
Available Models
Magnetic stirrers are modern devices designed for preparing solutions of solids and mixing liquids. They are used in laboratories, wherever there is a need for intensive mixing of liquids. Unlike motorized stirrers, non-motorized stirrers are characterized by the ability to operate at very low speeds, which makes them very useful for titration and dissolution of easily volatilized reagents.
Technical data of available models:
| Technical data | M-2 | M-5 | M-15 | M-20.20 | M-30.30 |
| Max. mixing volume | 1 l | 10 l | 10 l | 50 l | 100 l |
| Plate dimensions | 75x130 mm | 140x155 mm | 135x155 mm | 200x245 mm | 300x310 mm |
| Plate | polipropylene | CRES | |||
| RPM | 500 rpm | 60-1600 rpm | 60-1600 rpm | 100-1100 rpm | 100-1100 rpm |
| Speed control | constant speed | smooth | smooth | smooth | smooth |
| Model | Max vol. work [l] | Rotational speed [rpm] | Dimensions |
|---|---|---|---|
| M-2 | 1l | 500 | plate 75x130 mm |
| M-5 | 10 | 60-1600 | plate 140x155 mm |
| M-15 | 10 | 60-1600 | plate 135x155 mm |
| M-20.20 | 50 | 100-1100 | plate 200x245 mm |
| M-30.30 | 100 | 100-1100 | plate 300x310 mm |
