Classic Standard Autoclaves
Choose Models for offer request
Intended
- Autoclave capacity: 9 liters
- Fully automated sterilization process
- Short break between cycles
- Large working chamber capacity
- Double thermal safety fuse
- Certified
Characteristic
Available Models
Autoclave Features:
- Capacity: 9 liters (Standard)
- Sterilization cycles: 11 minutes at 126°C (210001), 3.5 minutes at 134°C (210134)
- Completely automated sterilization process
- Lightweight with a relatively large working chamber
- Convenient handles for easy transport
- Short required break between cycles (only 5 minutes)
- User-friendly - no special training required
- Rich equipment allows for use in general medicine, dentistry, beauty salons, veterinary practices, and laboratories.
Safety Features:
- Electronic detector shuts off power in case of insufficient water
- Double thermal safety fuse prevents uncontrolled temperature rise
- Compressed mechanical locking system prevents the lid from opening during a cycle
- Gasket Offset Device safeguards against excessive pressure due to improper loading
Certifications:
- IEC 601
- DIN 58946
- EMC: EN 50081-1
- EN 50082-1
- prEN 50082-2
- BS 3970 Part 4
Specifications:
| Technical specification | 210001 | 210134 |
|
Capacity [liters] |
9 | 9 |
|
Height [mm] |
335 | 335 |
|
Width [mm] |
340 | 340 |
|
Weight [kg] |
4 | 4,5 |
|
Chamber Diameter [mm] |
210 | 210 |
|
Chamber Height [mm] |
236 | 236 |
|
Maximum Instrument Length [mm] |
228 | 228 |
|
Maximum Load [kg] |
3 | 3 |
|
Sterilization Temperature [°C] |
126 | 134 |
|
Effective Sterilization Time [min] |
11 | 3,5 |
|
Total Cycle Time [min] |
22 | 22 |
|
Pressure [bar] |
1,4 | 2,2 |
|
Power Supply [V] |
230 | 230 |
|
Power [W] |
1500 | 1500 |
| Model | Capacity | Options |
|---|---|---|
| 210001 | 9 l | Effective sterilisation time 11 min |
| 210134 | 9 l | Effective sterilisation time 3.5 minutes |
