Binder MKT chambers
Choose Models for offer request
Intended
- Temperature range: -70 °C to 180 °C
- 4 potential-free relay connectors
- Programmable anti-glare protection for samples
- BINDER APT-COM™ 3 Basic Edition communication software
Characteristic
Available Models
Binder's MKT series dynamic chamber meets the highest standards in terms of precision and performance in periodic temperature tests , thanks to its temperature range of -70 °C to 180 °C and natural stimulation.
The MKF series devices not only allow materials to be tested within this temperature range, but also to regulate humidity from 10 to 98% relative humidity.
An efficient cooling system is integrated with high cooling speeds.
As an added bonus, sample sprinkler protection can be programmed, and four potential-free relay connectors can be activated with the MCS stervo.
In addition, the device is equipped with a vision window of environmental testing chambers additionally heated and equipped with LED interior lighting for good visibility.
The possibility of individualized programming of dynamic chambers makes the device extremely versatile and widely applicable.
High-quality housing insulation is used and the interior of the chambers and the inside sides of the doors are made of stainless steel, which is durable and easy to maintain.
Safety is ensured by a reliable diagnostic system along with optical and acoustic alarms.
Dynamic chambers meet the highest requirements for industrial materials testing and wear and strength testing.
The devices comply with commonly used IEC, MIL and EN standards.
All BINDER environmental test chambers are equipped with the proven APT.line™ preheating chamber technology, which ensures uniform temperature distribution and guarantees accurate measurements at any temperature setting.
Features:
- Intuitive touchscreen controller with timestep programming and real-time programming
- Internal data logger, measurement values in open format readable via USB
- Access port with silicone plug (model 115, 240: 50 mm, left)
- 2 access ports with silicone plug (model 720: 80 mm, left and right)
- Independent, adjustable Class 2 temperature protection with optical alarm
- 4 casters, two with brakes
- Interface for computer connection: Ethernet
- 230 V socket on the side panel on the right side
- Ramp function can be set
- Built-in line recorder
- Real-time clock
- Door heating
- 1 stainless steel wire shelf
- Stainless steel interior
- Halogen-free refrigerant R-452A and R-23
- Cooling provided by cascade compression refrigeration unit
Comparison of available models:
| Technical data | MKT115 | MKT240 | MKT720 |
| Volume | 115 l | 228 l | 734 l |
| Net weight | 305 kg | 380 kg | 610 kg |
| Housing dimensions | 980 x 1725 x 865 mm | 1115 x 1935 x 925 mm | 1580 x 2005 x 1140 mm |
| Chamber dimensions | 600 x 480 x 400 mm | 735 x 700 x 443 mm | 1200 x 1020 x 600 mm |
| Temperature range | -70 to 180 °C | -70 to 180 °C | -70 to 180 °C |
| Average heating speed | 5,3 K/min | 5 K/min | 4,5 K/min |
| Spatial variation of temperature dependig on the setpoint | 0.2-1.8 ± K | 0.1-1 ± K | 0.3-2 ± K |
| Temperature fluctuation epending on the setpoint | 0.1-0.6 ± K | 0.1-0.4 ± K | 0.1-0.5 ± K |
| Rated power | 5.5 kW | 6.5 kW | 13 kW |
| Model | Capacity | Mass | Dimensions |
|---|---|---|---|
| MKT 115 | 115 l | 305 kg | 980 x 1725 x 865 mm |
| MKT 240 | 228 l | 380 kg | 1115 x 1935 x 925 mm |
| MKT 720 | 734 l | 610 kg | 1580 x 2005 x 1140 mm |
