Binder MKFT chambers
Choose Models for offer request
Intended
- Temperature range: -70 °C to 180 °C
- Humidity range: 10 to 98% relative humidity.
- Built-in water storage tank with a capacity of 20l
- 4 potential-free relay connectors
Characteristic
Available Models
Binder MKFT series is a high-end equipment used for complex climate tests based on current standards due to its large power reserves and rapid cooling of the chamber. MKFT series is distinguished by an extended temperature range, humidity control, which will prove useful in the case of the need for rapid temperature changes.
Fast cooling, high precision and large capacity reserves make these devices suitable for complex climate studies as well.
A great advantage is the high accuracy of the indicator to one-tenth of a degree or percentage. In addition, the equipment, using a capacitive humidity sensor and steam humidification, has the function of adjusting the humidity inside the chamber.
An additional feature is programmable anti-glare protection. The vision window of the climate chambers is heated and equipped with LED interior lighting. Four potential-free relay connectors are activated by the MCS controller.
An innovative technique used in this device is the APT.line™ preheating technology, which ensures uniform and stable temperature distribution inside the chamber.
The use of "Advanced Preheating Technology" guarantees an express recovery time to the desired values.
The MKFT series of dynamic climate change chambers operate over a particularly wide temperature range of -70 °C to 180 °C, as well as a humidity range of 10% w. relative to 98% w. relative.
Technical data of available models:
| Technical data | MKFT115 | MKFT240 | MKFT720 |
| Volume | 115 | 228 | 734 |
| Net weight | 330 | 415 | 635 |
| ousing dimensions | 980 x 1725 x 865 | 1115 x 1940 x 925 | 1580 x 2005 x 1140 |
| Chamber dimensions | 600 x 480 x 400 | 735 x 700 x 443 | 1200 x 1020 x 600 |
| Temperature range | -70 to 180 [°C] | -70 to 180 [°C] | -70 to 180 [°C] |
| Spatial variation of temperature depending on the setpoint | 0.1-1.3 [± K] | 0.2-1.8 [± K] | 0.3-2 [± K] |
| Temperature fluctuation depending on the setpoint | 0.1-0.5 [± K] | 0.1-0.5 [± K] | 0.1-0.5 [± K] |
| rated power | 5.5kW | 6.5 kW | 13kW |
| Model | Capacity | Mass | Dimensions |
|---|---|---|---|
| MKFT 115 | 115 l | 330 kg | 980 x 1725 x 865 mm |
| MKFT 240 | 228 l | 415 kg | 1115 x 1940 x 925 mm |
| MKFT 720 | 734 l | 635 kg | 1580 x 2005 x 1140 mm |
