Binder MK chambers
Choose Models for offer request
Intended
- Temperature range: -40 °C to 180 °C
- APT.line™ preheating chamber technology
- Programmable anti-glare protection for samples
- Heated viewing window with internal LED lighting
Characteristic
Available Models
Dynamic chambers designed for environmental testing require high temperature profiles operating from -40 °C to 180 °C.
Due to their high precision and performance, they are used to test materials under varying climatic conditions.
Ze względu na wysoką precyzję i wydajność są one wykorzystywane do testowania materiałów w zmiennych warunkach klimatycznych.
Thanks to its fast operation, the chamber is able to stimulate a variety of climatic conditions, including extreme ones, making it possible to carry out research focusing on the effects of varying environmental conditions on a given material. This is of great importance in the automotive or metal industry, but also in aerospace or other industrial sectors.
The chambers perform excellently at very high and extremely low temperatures during stability and endurance tests, ensuring uniform temperature distribution, even when fully loaded.
All BINDER environmental test chambers are equipped with the proven APT.line™ preheating chamber technology, which ensures uniform temperature distribution and guarantees accurate measurements at any temperature setting.
The dynamic climate change chambers have been constructed in accordance with the state of the art, and in practical application they are efficient and durable, as well as precise and easy to operate
The high rate of temperature change of about 5K/min allows materials to be tested according to current standards.
The capacity of the MK series ranges from 60 to 734 liters, which is perfectly suited for periodic temperature testing.
Features:
- Communications software
- BINDER APT-COM™ 3 Basic Edition
- Diagnostic system with visual and audible alarms
- Intuitive touchscreen controller with timestep programming and real-time programming
- Internal data logger, measurement values in open format readable via USB
- Access port with silicone plug (model 56, 115, 240)
- 2 access ports with silicone plug (model 720)
- Independent, adjustable Class 2 temperature protection with optical alarm
- 4 casters, two with brakes
- Interface for computer connection: Ethernet
- 230-volt socket on the side panel on the right side
- (model 115, 240, 720)
- Ramp function can be set
- Built-in line recorder
- Door heating
- Halogen-free refrigerant R-452A
- Cooling provided by compressor unit
Technical data of available models:
| Technical data | MK56 | MK115 | MK240 | MK720 |
| Volume | 60 l | 115 l | 228 l | 734 l |
| Net weight | 168 kg | 260 kg | 340 kg | 570 kg |
| Housing dimensions | 400 x 420 x 350 mm | 600 x 480 x 400 mm | 735 x 700 x 443 mm | 1200 x 1020 x 600 mm |
| Chamber dimensions | 720 x 1445 x 778 mm | 980 x 1725 x 865 mm | 1115 x 1715 x 925 mm | 1580 x 2005 x 1140 mm |
| Temperature range | -40 to 180 °C | -40 to 180 °C | -40 to 181 °C | -40 to 182 °C |
| Spatial variation of temperature depending on the setpoint | 0.5-1.5 ± K | 0.1-0.2 ± K | 0.1-1.2 ± K | 0.32 ± K |
| Temperature fluctuaction depending on the setpoint | 0.1-0.5 ± K | 0.5-2 ± K | 0.1-0.5 ± K | 0.1-0.5 ± K |
| rated power | 2.8 kW | 3.5 kW | 5.6 kW | 8.7 kW |
| Model | Capacity | Mass | Dimensions |
|---|---|---|---|
| MK 56 | 60 l | 168 kg | 720 x 1445 x 778 mm |
| MK 115 | 115 l | 260 kg | 980 x 1725 x 865 mm |
| MK 240 | 228 l | 340 kg | 1115 x 1715 x 925 mm |
| MK 720 | 734 l | 570 kg | 1580 x 2005 x 1140 mm |
