BioBlood BR

Choose Models for offer request

Intended

• Temperature range + 2 ° C / + 6 ° C
• Additional temperature sensor
• BioLine air system
• Automatic defrosting
• BioBlood control

The BioBlood refrigerator is adapted to special requirements related to the controlled storage of blood, plasma, and blood-related products. These advanced devices have been developed exclusively for blood storage to ensure high, constant quality at every stage, from the donor to the transfusion. This means exceptionally rigorous specifications for all components.

BioBlood chambers also provide users with an excellent view of their contents. Glass doors allow you to see at a glance what is inside the cabinet, allowing control and access to it. BioBlood uses environmentally friendly natural foam propellants that do not contain HFC and is available with refrigerants that do not contain HFC.


Technical specification BR 500 BR 600D BR 600 W BR 930
Temperature range
+ 2 ° C / + 6 ° C


Ambient temperature range
solid door 10 ° C / 43 ° C; glass door 10 ° C / 38 ° C


Port
1 szt. Ø 24,5 mm


Dimensions (W X D X H) [mm]
600 x 806 x 2025/2275
695 x 876 x 1875/2125
815 x 756 x 1875/2125
780 x 1045 x 2025/2275
Net weight [kg]
130  146 146 165
Volume [l] 500 600 600 930
Modules of shelves and drawers
shelves 52 - drawers 13
shelves 24 - drawers 12
shelves 24 - drawers 12
shelves 52 - drawers 13
Refrigerant
R290 / R134a / prepared fo an external compressor / prepared for glycol
Air system
BioLine wentilated air distribution system
Defrosting system
Automatic intelligent defrosting with re-evaporation of defrost water
Model Temperature range [° C] Capacity Scale Dimensions
BR 500 +2 to +6 500 l 130 kg 600 x 806 x 2025/2275 mm
BR 600D +2 to +6 600 l 146 kg 695 x 876 x 1875/2125 mm
BR 600W +2 to +6 600 l 146 kg 815 x 756 x 1875/2125 mm
BR 930 +2 to +6 930 l 165 kg 780 x 1045 x 2025/2275 mm
