Termio temperature recorders
Choose Models for offer request
Intended
- LCD display
- Case dimensions 45x100x19 mm
- Power supply 1/2xAA 3.6V battery
- USB interface
- Memory for 32000 measurements
- Temperature measurement in °C
- Resolution 0.1 °C
- Registration signaling
- Access to maximum and minimum values
- Low battery indication
Characteristic
Available Models
Termio temperature recorder is a high-precision thermometer that allows memory recording of up to 32,000 data. This logger allows you to measure and record the temperature very accurately or at low cost. This device allows you to read the temperature over a wide range. It is used for measurements in refrigerators, cold stores, pharmaceutical industry, laboratories, food or cosmetic industry.
The recorder is equipped with a 3 ½-digit LCD display which allows the temperature to be displayed with a resolution of 0.01 °C. The accuracy of the recorder is determined individually in the calibration process. These devices record measurements at a frequency of 1 minute and above. Switching on and off the recording can be done repeatedly using the keyboard located on the device panel. Then successive files of recorded data are created in the device's memory, which can be conveniently viewed, printed and saved in .txt or .pdf format.
Technical specification:
| Technical data | TERMIO | TERMIO-15 | TERMIO-31 | TERMIO-1 | TERMIO-2 |
| Measured temperature range | -30°C to 70°C | -30°C do 70°C with built-in sensor | -200°C to 1400°C with external probe | 30°C do 70°C with built-in sensor | -50°C to 300°C |
| Operating temperature range | -30°C to 70°C | -30°C to 70°C | -30°C to 40°C | -30°C to 70°C | -30°C to 40°C |
| Resolution | Over the entire measuring range 0.1°C | Over the entire measuring range 0.01°C | In the measuring range of -200°C to 1000°C is 0.1°C in the rest of the range 1°C | Over the entire measuring range 0.01°C | Over the entire measuring range 0.01°C |
| Accuracy | -/+0.5°C or better in the measurement range of -10°C to 40°C -/+1°C in the remaining measurement range |
-/+0,3°C | -/+0.6°C in the measurement range of -10°C to 150°C;-/+1°C or better in the range of 151°C to 250°C | -/+0,3°C | -10°C to 100°C: -/+0,07°C |
| Battery life | 1000 000 records | 12 months | 1000 000 records | 12 months | 12 months |
| Model | Temperature [° C] | Working conditions |
|---|---|---|
| TERMIO | -30°C to 70°C | -30°C to 70°C |
| TERMIO-15 | -30°C to 70°C | -30°C to 70°C |
| TERMIO-31 | -200°C to 1400°C | -30°C to 40°C |
| TERMIO-1 | -30°C to 70°C | -30°C to 70°C |
| TERMIO-2 | -50°C to 300°C | -30°C to 40°C |
