    1-6-block heating blocks

    Choose Models for offer request

    Product Sheet

    Intended

    • iso-9001-copy
    • shape-2601
    • shape-2680
    • iso-9001-copy
    • shape-2601
    • shape-2680
    • 2/4/6 blocks
    • Interchangeable blocks possible
    • High repeatability of results
    • Digital or analog control

    • Characteristic

    • Available Models


    Versatile heating blocks for everyday use with accessories for every application


    Manufacturer OHAUS offers three models of two-station heating blocks. They are adapted to different needs. All models provide extremely even and stable temperatures. The heated lid heating block has a second heating module in the lid that minimizes condensation to maintain sample integrity. This ensures reproducible and reliable results by preventing sample contamination. Digital models offer a unique one-point calibration feature to match the heating block's display readings to a known outdoor temperature standard for 3 temperature setpoints.


    Four-seat and six-seat blocks are also available, along with a range of retrofits.


    Features:
    • Even and stable temperature
    Three models to suit different needs. All models provide extremely even and stable temperatures.

    • Minimize condensation
    Avoid contamination to ensure reproducible and reliable results. The heated lid heating block has a second heating module in the lid to minimize condensation to maintain sample integrity.

    • Single point calibration
    Digital models offer a unique one-point calibration function to match the heating block display to a known outdoor temperature pattern for 3 temperature setpoints.

    2-block heating blocks:

    Model HB2AL HB2DG HB2DGHL
    Control Analog Digital
    Temperature range [°C] Low: ambient temp + 5 – 100,
    High: 75 – 150    		 Ambient temp. + 5 – 120 Ambient temp. + 5 – 100
    Stability at 37°C [°C] ± 1,5 ± 0,1
    Stability in the block at temp 37°C [°C] ± 0,1
    Heatng time to 100°C [min] ≤16 ≤ 30
    Temperature calibration N/A •
    Number of blocks 2
    Protection against overheating N/A 10°C above the defined value
    Work conditions 18°C to 33°C, relative humidity 20-80%, non-condensing
    Power supply [V] 230 V
    Power [W] 210 400
    Dimensions [W × L × H] mm 203 × 391 × 89 203 × 391 × 178
    Net mass [kg] 2.8 3.1
    Catalog no 30392047 30392061 30392103


    4-block heating blocks:

    Model HB4AL HB4DG
    Control Analog Digital
    Temperature range [°C] Low: ambient temp + 5 – 100,
    High: 75 – 150    		 Ambient temp + 5 – 120
    Stability at 37°C [°C] ± 2,5 ± 0,2
    Stability in the block at temp 37°C [°C] ± 0,4 ± 0,2
    Heating time to 100°C [min] ≤ 23
    Temperature calibration N/A •
    Number of blocks 4
    Protection against overheating N/A 10°C above the defined value
    Work conditions 18°C to 33°C, relative humidity 20-89%, non-condensing
    Power supply [V] 230
    Power [W] 310
    Dimensions [W × L × H] [mm] 203 × 429 × 89
    Net mass [kg] 3.8
    Catalog no 30392068 30392089


    6-block heating blocks:

    Model HB6AL HB6DG
    Control Analog Digital
    Temperature range [°C] Low: ambient temp + 5 – 100,
    High: 75 – 150    		 Ambient temp + 5 – 120
    Stability at temp 37°C [°C] ± 2,5 ± 0,2
    Stability in the block at temp 37°C [°C] ± 0,2
    Heating time to 100°C [min] ≤ 30
    Temperature calibration N/A •
    Number of blocks 6
    Protection against overheating N/A 10°C above the defined value
    Warunki pracy 18°C to 33°C, relative humidity 20-80%, non-cpndensing
    Power supply [V] 230
    Power [W] 410
    Dimensions [W × L × H] [mm] 203 × 531 × 89
    Net mass [kg] 4.4
    Catalog no 30392075 30392096
    Model Temperature [° C]
    HB2AL Temperature range Low range: Ambient temp. + 5°C - 100°C; High range: 75°C - 150°C
    HB2DG Ambient temp. + 5°C - 100°C
    HB2DGHL Ambient temp. + 5°C - 100°C
    HB4AL Temperature Range Low: Ambient temp. + 5 - 100, High: 75 - 150
    HB4DG Temperature range Ambient temp. + 5 - 120
    HB6AL Temperature Range Low: Ambient temp. + 5 - 100, High: 75 - 150
    HB6DG Temperature range Ambient temp. + 5 - 120
