1-4 block IKA heating blocks
Choose Models for offer request
Intended
- Infinitely variable temperature control
- Countdown backwards
- Temperature sensor
- Error code indicator
Characteristic
Available Models
Heating blocks, aluminum with digital control, allow precise temperature control in small vessels. The included PT-1000 temperature sensor facilitates heat measurement directly in the sample dish. The heating blocks are used for PCR dishes and strips, Greiner tubes, microplates and cuvettes. The heating block is ideal for determining melting and boiling temperatures, performing enzymatic reactions, activating cultures, immunoassays, DNA denaturation, culture media samples, coagulation studies, determining blood, urea and nitrogen levels, and in situ hybridization.
Features:- Stepless temperature control up to 120°C level
- Timer: Countdown backwards, adjustable from 1 min to 99 h 59 min
- Counter: indication of heating time
- Very versatile, with a large number of blocks
- Error code indicator
- Fixed safety circuit
- Audible indication of test completion
| Technical data | DRY BLOCK HEATER 1 | DRY BLOCK HEATER 2 | DRY BLOCK HEATER 3 | DRY BLOCK HEATER 4 |
| Number of blocks | 1 | 2 | 3 | 4 |
| Heating power | 165 W | 250 W | 330 W | 412 W |
| Temperature range | +5°C - 120 °C | |||
| Connection to external temperature sensor | CT(DIN 12878) | |||
| Temperature uniformity at 37/60°C | 0,2 K/ 0,4 K | 0,2 K/ 0,4 K | 0,3 K/ 0,6 K | 0,3 K/ 0,6 K |
| Dimensions of the cooktop | 96 x 76 mm | 96 x 152 mm | 96 x 228 mm | 96 x 304 mm |
| Dimensions (W x L x H) | 151 x 73 x 228 mm | 151 x 73 x 304 mm | 151 x 73 x 380 mm | 151 x 73 x 456 mm |
| Model | Description |
|---|---|
| DRY BLOCK HEATER 1 | 1 heat block |
| DRY BLOCK HEATER 2 | 2 heat blocks |
| DRY BLOCK HEATER 3 | 3 heat blocks |
| DRY BLOCK HEATER 4 | 4 heat blocks |
