Binder KBF climate chambers

Choose Models for offer request

Intended

  • iso-9001-copy
  • shape-2601
  • shape-2706
  • iso-9001-copy
  • shape-2601
  • shape-2706
  • Even climatic conditions thanks to the APT.line™ preheating chamber
  • Automatic water and waste water management
  • Fast-response steam humidification

Binder climate chambers are used when studying the behavior of materials under conditions of constant humidity and temperature.

The devices operate in a temperature range of 0 °C to 70 °C, and in a humidity range of 10% to 80% relative value.

The distinguishing features of the Binder KBF are absolutely reliable stability tests and accurate maintenance of constant climatic conditions.

Precise maintenance of climatic conditions makes the chambers great for stability tests.

Efficient operation is provided by a USB port for data logging and cases for reading measurement values.

It is ideal to use an intuitive controller equipped with a touch screen with timestep programming and real-time programming, making the device comfortable and easy to use.

The climate chamber is designed on the basis of modular construction and the interior is covered with stainless steel, which allows easy cleaning of the equipment.

The use of APT.line™ preheating technology results in the circulation of usable volume air smoothly and evenly.

Poziom wilgotności można precyzyjnie regulować i w ten sposób całkowicie dostosować do poszczególnych wymagań.

Key features

  • Temperature range: 0 °C to 70 °C
  • Humidity range of 10 to 80% relative humidity.
  • APT.line™ preheating chamber technology
  • Humidity control with capacitive humidity sensor and evaporative humidification
  • Intuitive touchscreen controller with timestep programming and real-time programming
  • BINDER Multi Management Software APT-COM™ Basic Edition
  • Internal data logger, measurement values in open format readable via USB
  • Device self-test for comprehensive status analysis
  • Sealed inner door made of safety glass (ESG)
  • Prevention of glass corrosion with special TIMELESS coating
  • Internal compartment made entirely of stainless steel
  • 2 stainless steel wire shelves
  • Access port with 30 mm silicone plug, left side
  • 4 stable casters, two with brakes, from 240 L capacity
  • Class 3.1 temperature sensor (DIN 12880) with optical and acoustic temperature alarm
  • Interface for computer connection: Ethernet
  • Door heating



Comparison of available models:

Tehnical data KBF115 KBF240 KBF720 KBF1020
Volume 102 l 247 l 700 l 1020 l
Net weight 129 kg 189 kg 312 kg 379 kg
Housing dimensions 880 x 1050 x 650 mm 925 x 1460 x 800 mm 1250 x 1925 x 890 mm 1250 x 1925 x 1145 mm
Chamber dimensions 600 x 483 x 351 mm 650 x 785 x 485 mm 973 x 1250 x 576 mm 976 x 1250 x 836 mm
Temperature range 0-70°C 0-70°C 0-70°C 0-70°C
Spatial variation f temperature at 40 °C 0.2 ± K 0.3 ± K 0.2 ± K 0.2 ± K
Temperature fluctuation 0.1 ± K 0.1 ± K 0.2 ± K 0.5 ± K
Max. amount of heat that can be compensated at 40 °C 300 W 300 W 600 W 600 W
Power 2 kW 2.1 kW 3.1 kW 3.1 kW





Model Capacity Dimensions
KBF-115 cat. no.: 9020-0320 102 l W880 x H1050 x D650 mm
KBF-240 cat. no.: 9020-0322 247 l W925 x H1460 x D800 mm
KBF-720 cat. no.: 9020-0324 700 l W1250 x H1925 x D890 mm
KBF-1020 cat. no.: 9020-0326 1020 l W1250 x H1925 x D1145 mm
