Benchtop Fume Hoods for Connection to Building Ventilation
Choose Models for offer request
Intended
- Ideal for laboratories with the possibility of connecting to the laboratory's ventilation system
- 15/10 steel construction
- Epoxy paint finish in white RAL 9010, resistant to chemicals
- Walls made of transparent PMMA
- High level of safety
- Front glass with two work openings or one larger opening
- Two sealed technical ports in the rear wall and one in each side wall, allowing the passage of power cables for devices
Characteristic
Available Models
Benchtop fume hoods designed for laboratories with the option of connecting to the building's ventilation system. The use of filterless technology allows for the removal of toxic and harmful fumes outside the building.
Fume hoods are available in 4 widths: 600, 900, 1200, and 1500 mm, making it easy to adapt them to laboratory tables of various sizes.
Fume hoods are made of "optical" polycarbonate, which is clear and does not distort the view. The material ensures good visibility within a 360° range of what is happening inside the fume hood.
Easy access to equipment, even of large volume, thanks to the special design of the front panel. Maximum safety is ensured by forearm holes for work when the front panel is closed, as well as the passage of electrical cables and media cables inside the digester through 2 cable holes located in the side walls and two on the rear wall.
Additional Accessories:
- Compatible CDV-A fan
- KRC connection kit
- Worktop made of melamine
- Worktop made of tempered glass
- LED chamber lighting
- Retentive tank for spilled chemicals under the worktop
- 2-door chemical cabinet under the digester on wheels
- Opened cabinet under the digester on wheels
- Frame for the fume hood
Comparison of available models
Model | External dimensions (H x W x D) | Internal dimensions (H x W x D) | Weight | Work slots |
BH06D | 745 x 600 x 650 mm | 735 x 545 x 505 mm | 23 kg | Two, triangular |
BH06Z | 745 x 600 x 650 mm | 735 x 545 x 505 mm | 23 kg | One, trapezoidal |
BH09D | 945 x 900 x 750 mm | 935 x 845 x 700 mm | 34 kg | Two, triangular |
BH09Z | 945 x 900 x 750 mm | 935 x 845 x 700 mm | 34 kg | One, trapezoidal |
BH12D | 945 x 1200 x 750 mm | 935 x 1145 x 700 mm | 44 kg | Two, triangular |
BH12Z | 945 x 1200 x 750 mm | 935 x 1145 x 700 mm | 44 kg | One, trapezoidal |
BH15D | 945 x 1500 x 750 mm | 935 x 1445 x 700 mm | 54 kg | Two, triangular |
BH15Z | 945 x 1500 x 750 mm | 935 x 1445 x 700 mm | 54 kg | One, trapezoidal |
BH15G | 945 x 1500 x 750 mm | 935 x 1445 x 700 mm | 54 kg | One, trapezoidal |
Model | Dimensions | Other |
---|---|---|
Dygestorium BH06D+ nr kat.: BH06D+ | W600xD650xH745 mm | Two, triangular slots |
Dygestorium BH06Z+ nr kat.: BH06Z+ | W600xD650xH745 mm | One, trapezoidal slot |
Dygestorium BH09D+ nr kat.: BH09D+ | W900xD750xH945 mm | Two, triangular slots |
Dygestorium BH09Z+ nr kat.: BH09Z+ | W900xD750xH945 mm | One, trapezoidal slot |
Dygestorium BH12D+ nr kat.: BH12D+ | W1200xD750xH945 mm | Two, triangular slots |
Dygestorium BH12Z+ nr kat.: BH12Z+ | W1200xD750xH945 mm | One, trapezoidal slot |
Dygestorium BH15D+ nr kat.: BH15D+ | W1500xD750xH945 mm | Two, triangular slots |
Dygestorium BH15Z+ nr kat.: BH15Z+ | W1500xD750xH945 mm | One, trapezoidal slot |
Dygestorium BH15G+ nr kat.: BH15G+ | W1500xD750xH945 mm | One, trapezoidal slot |
Dygestorium BH18Z+ nr kat.: BH18G+ | W1800xD750xH1240 mm | One, trapezoidal slot |
Dygestorium BH18G+ nr kat.: BH18G+ | W1800xD750xH1240 mm | One, trapezoidal slot |
